Model | ZL38-08B | |||||||
Working Voltage Range | DC: 6-24V | |||||||
Rating Power | 6V: 0-17W / 12V: 0-17W / 24V: 0-25W | |||||||
Static Water Head | 0-6 M | |||||||
Static Flow Rate | 0-12 L/min | |||||||
Lifespan | Continuous operation≤24hrs, under normal working surrounding >20000Hr | |||||||
Working Environment | Liquid: From weak acid to weak base, workable on land (Non submersible) | |||||||
Max Noise | Under normal working status, 1M distance over test instrument <40dB | |||||||
Max Working Temperature | Under normal surroundings, fluid medium temperature≤90℃ | |||||||
Application | solar water heater, hot water shower, Hot shower, solar water circulation system, Small fountain, Aquarium, etc. | |||||||
Size | IP Grade | Inlet | Outlet | Remark | ||||
Length（mm） | Width（mm） | Height（mm） | OD（inch） | ID（mm） | OD（inch） | ID（mm） | Inlet and outlet with forward spinning Screw pipe thread | |
96 | 48 | 90 | IP67 | G1/2〞Standard pipe thread | φ13 | G1/2〞Standard pipe thread | φ13 | |
Remark: It’s for reference only, the one based on the customer’s endorsement demands shall prevail!
